In the control center of a modern factory, rows of neatly arranged electrical control cabinets resemble the conductor's podium of an industrial symphony. However, beneath this orderly appearance, the installation method of traditional solid state relays has become a bottleneck for system upgrades and maintenance - complex wiring, limited scalability, and lengthy commissioning times. With the in-depth advancement of Industry 4.0, this discrete design pattern is no longer capable of meeting the demands of flexible production and rapid response.

Gordon Electric has keenly perceived this trend and taken the lead in launching a modular solid-state relay system. Through innovative hardware architecture and intelligent connection technology, it has upgraded the traditional point-to-point control to a networked and configurable system solution, bringing about a profound architectural revolution to the industrial control field.

From Discrete to Integrated: A Breakthrough in Modular Design Concept

Traditional solid-state relays exist as independent units, with each relay requiring separate power supply, control lines, and load lines for connection. Godel's modular solution has completely transformed this model:

Standardized interface design:

The DIN rail mounting modules with a uniform width of 48mm are available in heights ranging from 75mm to 150mm.

The self-locking terminal blocks are adopted, allowing for wire connection without tools and reducing the wiring time by 70%.

The modules are connected through a standardized backplane bus, and power and control signals are automatically transmitted.

Scalable architecture:

The basic unit supports 8-channel output and can be seamlessly expanded to 128 channels through expansion modules.

Hot-swappable design allows for the replacement or addition of modules while the system is running.

Each module is independently addressed, supporting flexible address allocation and logical grouping.

Intelligent Diagnosis Interface:

Each output is equipped with an independent status indicator light, supporting red, yellow and green three-color display.

It is equipped with an internal self-diagnostic circuit that can detect abnormal conditions such as open circuit, short circuit and overheating of the load.

It provides standard Modbus TCP/IP or PROFINET interfaces for direct connection to industrial Ethernet.

In the renovation project of the welding and assembly workshop of a certain automobile manufacturing plant in North China, after adopting the Gorden modular system, the wiring inside the control cabinet was reduced by 85%, the cabinet size was reduced by 40%, and the system debugging time was shortened from the original three weeks to four days.

Integrated intelligent distribution and protection

GODEN highly integrates distribution, protection and control functions:

Integrated power management:

Each module is equipped with an isolated DC/DC power supply and supports a wide input range of 12-48VDC.

Multiple modules can share a high-power central power supply, improving energy efficiency and reducing costs.

Intelligent power distribution algorithm to prevent system restart due to momentary overload.

Multi-level protection strategy:

Chip-level protection: Each output MOSFET is equipped with an internal temperature sensor and overcurrent detection.

Module-level protection: Independent fuses and voltage transient suppressors

System-level protection: The central controller monitors the overall load conditions and implements preventive protection.

Configurable protection parameters:

The overcurrent protection threshold can be set within the range of 50% to 150% of the rated value through software.

The overheat protection point is programmable to adapt to different heat dissipation conditions and ambient temperatures.

The available fault recovery strategies are: automatic retry, lock and alarm, or reduced capacity operation.

After adopting the Godel modular solution for the cleanroom environment control system in a certain semiconductor factory, precise protection for over 800 fans and heaters was achieved. During the three years of system operation, there was not a single shutdown caused by incorrect protective actions.

Software-defined Functionality: Flexibly Adapting to Diverse Needs

Gordon has developed powerful configuration software to achieve "software-defined relays":

Visual programming interface:

Drag-and-drop logic editing enables complex control logic to be implemented without writing code.

Pre-set more than 50 commonly used function blocks, such as timers, counters, comparators, PID regulators, etc.

Supports offline simulation and online debugging, significantly shortening the development cycle.

Parametric configuration:

Each output channel can be independently configured as normally open, normally closed, pulse output, and other modes.

The switch delay time can be precisely set, ranging from 1ms to 10 seconds and adjustable.

Optimization parameter templates for different load types, one-click application.

Remote Management and Monitoring:

Remote parameter configuration and firmware upgrade can be achieved via Ethernet or Wi-Fi.

Real-time monitoring of the operating data such as current, temperature and switch count of each output channel.

Generate operation reports and fault analysis reports, and support predictive maintenance.

A certain intelligent warehousing system integrator in South China has reported that after using the Godel modular system, the time required to customize control solutions for different clients has been reduced from an average of two weeks to three days, significantly enhancing the competitiveness of their products.

Industry-specific solutions

To meet the unique requirements of various industries, Godel has developed a series of dedicated modules:

Specialized modules for packaging machinery:

High-speed response version, with a switching time of less than 1 ms.

Integrated electronic cam function, supporting complex motion control.

Enhanced anti-interference design, suitable for environments with a high density of frequency converters.

Specialized modules for building automation:

Low power consumption design, standby current less than 0.1mA

Integrated KNX or BACnet protocol interface

Support astronomical clock and scene control functions

Specialized module for process control:

High-precision analog quantity detection, 16-bit ADC resolution

Isolated thermocouple and RTD input interface

Compliant with SIL2 safety level certification

In the renovation of the automatic control system of a water treatment plant in Southwest China, the Godel process control dedicated module achieved precise control over parameters such as pH value, turbidity and residual chlorine, and the system control accuracy was improved to ±0.5%, with a 18% reduction in chemical consumption.

Revolutionary simplification of installation and maintenance

Modular design has brought about a fundamental change in maintenance methods:

Quick system installation:

Pre-assembled installation guide rails and wiring base

Color-coded connectors and cables

The wiring diagram and address table are automatically generated by scanning the QR code.

Modular spare parts strategy:

Standardized modules reduce the variety of spare parts and inventory costs.

The faulty module can be replaced within five minutes.

Support module repair and refurbishment services

Intelligent diagnostic tool:

The handheld diagnostic instrument can quickly locate the fault point.

The mobile phone APP reads the operation data through the NFC reading module.

The cloud service platform provides remote technical support.

Global maintenance data from a multinational food company shows that after adopting the Gordon modular system, the average mean time to repair (MTTR) dropped from 4.5 hours to 45 minutes, and the overall equipment effectiveness (OEE) increased by 3.2 percentage points.

Economic Benefits and Return on Investment

Modular systems create value in multiple dimensions:

Optimization of initial investment:

Reduce the number of cabinets and floor space, saving 15-25% on hardware investment.

Reduce wiring costs and installation labor expenses by 30-40%

Shorten the project cycle and bring the production online ahead of schedule to generate profits.

Reduced operating costs:

Energy consumption reduction: Smart power management reduces standby power consumption.

Maintenance cost: Modular replacement reduces maintenance expenses and downtime losses.

Expansion cost: No need to rewire for later renovations, saving more than 50% of renovation costs.

Lifetime value:

10-year design life, supports online firmware upgrade to extend service life

The material recovery rate is as high as 90%, meeting the requirements of a circular economy.

The system can be relocated and reused as a whole, protecting the investment value.

An analysis of a certain electronic manufacturing enterprise in East China shows that after adopting the Godel modular system, the total cost of ownership (TCO) within three years was reduced by 28% compared to the traditional solution, and the payback period was only 1.7 years.

Future Outlook: Evolving towards Edge Computing Nodes

Gordon is taking modular solid-state relays to new heights:

Edge computing capabilities:

Equipped with an ARM Cortex-M7 processor for local data processing.

Support machine learning algorithms to achieve adaptive control.

Data preprocessing reduces the burden of cloud transmission.

Digital Twin Interface:

Generate digital models that comply with the Asset Administration Shell standard.

Real-time synchronization of physical state and virtual state

Support predictive maintenance and virtual commissioning

Enhanced security features:

Secure communication in compliance with IEC 62443 standard

Hardware-level encryption and identity authentication

Security event logs and audit trails

Modularization is not merely a change in the physical form of products, but also a revolution in industrial control thinking. Through the modular solid-state relay system, Gorden Electric provides users with a future-oriented control platform - flexible and scalable, intelligent and easy to maintain, and energy-efficient. In the wave of industrial digital transformation, we are not only providers of products, but also leaders and enablers of new industrial control architectures.

Choosing the Gorden modular system means choosing flexibility and foresight to meet future challenges. Let's join hands to build a smarter, more efficient and more sustainable industrial future together.
